Clarified Mango Juice vs Cloudy Mango Juice: What’s the Difference?

Mango juice is one of the most popular tropical fruit beverages in the global fruit juice market. Mango juice can be divided into two types according to different processing processes: Clarified Mango Juice and Cloud Mango Juice. Although fresh mango is used as raw material, there are obvious differences in appearance, processing technology, equipment configuration, taste and market application.

Understanding the differences between clear and cloudy juice is very important for enterprises planning to build a mango juice processing plant or optimize their existing production lines.

What are Clear and Cloudy Mango Juice?

Clear Mango Juice: Clear mango juice is a clear juice obtained by processing mangoes through enzymatic hydrolysis, clarification, and filtration to remove pulp particles, pectin, and some fiber.

Its characteristics include:

Clear and transparent appearance

Low viscosity

A more refreshing taste

High stability, not prone to sedimentation

Clear juice is commonly used for:

Concentrated fruit juice

Beverage base

Fruit-flavored beverages

Ingredients for carbonated beverages

Cloudy Mango Juice

Cloudy mango juice retains the fiber, pectin, and natural particles from the fruit pulp. Homogenization process ensures the fruit pulp is evenly suspended in the juice.

Its characteristics include:

Cloudy and thick appearance

Distinct fruit pulp texture

Taste closer to fresh fruit

More complete nutrient retention

Cloudy juice is widely used for:

NFC mango juice

Mango pulp beverages

Premium health drinks

Freshly squeezed fruit juice beverages

In short: Clear juice is "filtered, transparent fruit juice," while cloudy juice is "natural fruit juice that retains the fruit pulp fiber."

A Table to Understand the Difference Between Clear and Cloudy

Mango Clear Juice Production  Processing Technology:

In industrial production, clear juice production lines emphasize "clarity" and "stability."

Typical Process Flow:

Mango → Washing → Sorting → Pitting and pulping → Enzymatic hydrolysis → Fine filtration → Sterilization → Bottling

The most crucial steps include:

1. Enzymatic Hydrolysis Treatment

Because mangoes contain a large amount of pectin and fiber, direct filtration easily clogs the equipment. Therefore, pectinase is added to break down the pectin, reduce viscosity, and improve filtration efficiency.

2. Fine Filtration

The filtration system removes fruit pulp particles and suspended solids, resulting in a clear juice.

Common equipment includes:

Plate and frame filters

Membrane filtration equipment

Centrifuges

In large-scale industrial production, ultrafiltration systems are also used to further enhance clarification.

Mango Cloudy Juice Production Process

Unlike clear juice, cloudy juice production focuses on preserving the fruit pulp and its natural flavor.

Typical process flow:

Mango → Washing → Sorting → Pitting and pulping → Coarse filtration → Homogenization → Deaeration → Sterilization → Bottling

Core processes include:

1. Homogenization Treatment

The homogenizer uses high pressure to refine the fruit pulp particles, distributing them evenly throughout the juice and preventing significant stratification and sedimentation.

2. Deaeration Treatment

The deaerator removes oxygen from the juice, reducing oxidative browning and improving product stability and taste.

Due to the high viscosity and fiber content of mango pulp, tubular UHT sterilizers are typically more suitable for cloudy juice production to reduce the risk of clogging.

 Why is most mango juice on the market cloudy? This is because the typical flavor, natural color, and nutrients of a mango are mostly found in the pulp.

If these particles are completely removed using ultrafiltration:

The mango aroma will be weakened

The color will become lighter

The texture will become thinner.

Therefore, most pure mango juice products retain a certain amount of pulp to achieve better flavor and market acceptance.

In recent years, as consumers increasingly prefer beverages that are "natural," "less processed," and have a "real fruit pulp feel," the market demand for cloudy mango juice and NFC (Not From Concentrate) juice has continued to grow.

Main Equipment for Mango Juice Production Lines

Different types of mango juice require different equipment configurations.

Mango Juice Production Equipment

Mango Washing Machine

Pitting and Pulping Machine

Enzymatic Hydrolysis Tank

Fine Filtration System

Centrifuge

Sterilizer

Filling Machine

Mango Cloudy Juice Production Equipment

Washing Machine

Pulping Machine

Homogeneer

Deaerator

Tubular UHT Sterilizer

Aseptic Filling Machine

You can also learn more about related equipment:

Mango Juice Processing Line

Mango Pulp Production Line

Tubular UHT Sterilizer

Conclusion

The biggest difference between clear and cloudy mango juice lies in whether or not the fruit pulp fibers and natural particles are retained. Clear juice is more transparent and stable, while cloudy juice has a richer fruit aroma and a more complex taste.

For beverage manufacturers, different product positioning corresponds to different production processes and equipment solutions. With the continuous growth of global consumer demand for natural fruit juice, the mango cloudy juice and NFC juice market is developing rapidly.

If you would like to learn more about mango juice production lines, equipment configurations, or plant construction solutions, please contact us. We can provide you with free production solutions and equipment quotations.
