Performance characteristic
Flexibility and general usage
The system can undertake single process such as acerbity cleaning, alkali cleaning, and hot water cleaning, and also can take completely automatic cleaning according to the cleaning process designed. Besides, it can control the growing of micro chemicals.
Safety and reliance
Dense acid liquid and alkali liquid are completed in the underground
dense acid liquid & alkali tank ; the liquid level is controlled automatically ,fixed with overflow protecting system and unique material outlet construction can prevent crystallization from the cleaning liquid to block the pipe.
Economics and high efficiency
This equipment greatly reduces the cleaning time and increase the work efficiency compared with cleaning by hand; the use of cleaning liquid and water is more reasonable; meanwhile steam cost is relatively small, so to make full use of energy, and reduce the cleaning cost.
| Main technical parameters | |
| Name | Simple instruction |
| Alkali pot | Material SUS316L,conic top and tonic bottom, thickness: 50mm, keeping warm |
| Acerbity pot | Material SUS316L,conic top and tonic bottom,thickness: 50mm, keeping warm |
| Hot water pot | Material SUS304,conic top and tonic bottom, thickness: 50mm,keeping warm |
| Clean water pot | Material SUS304,conic top and tonic bottom, thickness: 50mm,keeping warm |
| Dense acerbity and alkali pot | Material SUS 316, single layer |
| Steam motored film pump | Acid and alkali resistant plastic, Flow:1000L/H |
| Advancement pump | Material SUS316, lift 20m, flow: 36m3/h, electric motor: 5.5kw |
| Plate heat exchanger | Material SUS316 |
| Filter | Material SUS304 |
| Returning pump. self-priming pump | Material SUS316,lift: 20m,flow: 20m3/h,electric motor: 4kw |
