Characteristic
1. The temperature within the Rotary Retorts is very stable, and heat distribution is uniform.
2. Quick Temperature Rising.
3. The direct heating and cooling, raise the production efficiency
4. Perfect pressure control ,which is suitable for the sterilization of gas-included packages.
5. Suitable for various packing materials.
6. All of the sterilizing courses can be controlled by computer PLC
7. The sterilizing retort adopts stimulative temperature control system, and multilevel heating system can be set
8. The function of f value measurement
9. The computer can store at least 30 sterilizing formulas
Applicable scope
For all heat resistant and waterproof package material
1.Glass container; glass bottle, glass jar
2.Mental can: tin can. tin canned, aluminum can
3.Plastic container serial: PP bottles, HDPE bottles
4. Flexible pouch serial: flexible retort pouch, laminated foil bag.high temperature cooking bag. vacuum bag.
| Main technical parameters | ||||||||||||
| Model | Outside measurement(mm) | Inner diameter (mm) | Length (mm) | Capacity (m3) | Thickness of autoclave (m) | Max working pressure (Mpa) | Max working temperature (℃) | Weight (kg) | Operating Weight (kg) | Power (Kw) | ||
| (L) | (W) | (H) | ||||||||||
| PLZ.10-1.B.4 | 1950 | 1200 | 1850 | 1000 | 900 | 1.00 | 4 | 0.3 | 147 | 560 | 860 | 6 |
| PLZ.10-2.B.4 | 3000 | 1200 | 1850 | 1000 | 1800 | 1.80 | 4 | 0.3 | 147 | 650 | 1250 | 8.5 |
| PLZ.12-2.B.4 | 3100 | 1500 | 2240 | 1200 | 1800 | 2.60 | 5 | 0.3 | 147 | 860 | 1400 | 13.5 |
| PLZ.12-3.B.4 | 4100 | 1500 | 2240 | 1200 | 2700 | 3.70 | 5 | 0.3 | 147 | 1200 | 1800 | 15.5 |
| PLZ.12-4.B.4 | 5020 | 1500 | 2340 | 1200 | 3600 | 4.80 | 5 | 0.3 | 147 | 1300 | 2100 | 18.5 |
| PLZ.13-4.B.4 | 5020 | 1600 | 2540 | 1300 | 3600 | 5.70 | 5 | 0.3 | 147 | 1500 | 2300 | 26.5 |
